- LED
HSOL
Inset Heliports Light
COMPLIANT with the Current Edition of the following Specs:
ICAO: Annex 14 - Volume I
IEC: TS 61827
NATO: STANAG 3619
IEC: TS 61827
NATO: STANAG 3619
DIMENSIONS:
Diameter: 8"
Protrusion: 6.3 mm
Fixture Depth: 101 mm
Base Depth: 125 mm
Protrusion: 6.3 mm
Fixture Depth: 101 mm
Base Depth: 125 mm
CONSUMPTIONS:
FATO White: 75 W 12 V
Edge Green: 45W 6.6 A or 35 W 12 V
Edge Yellow: 45W 6.6 A or 50 W 12 V
Edge Green: 45W 6.6 A or 35 W 12 V
Edge Yellow: 45W 6.6 A or 50 W 12 V
MAIN OPTIONS:
Fuse Cut-out: electric device, placed in parallel with each lamp, that ensures the continuity of the secondary circuit in case of lamp failure.
